Handheld Non Contact Surface Roughness Gauge

1. Handheld Non Contact Surface Roughness Gauge adopted pull aluminum mold design, durable, anti-electromagnetic interference ability significantly, in line with the design of the new trend. 2. Using

Product Recommendation

  • Product Introduction
  • Product Parameter
  • Product Picture
  • Product Comment

Introduction of Handheld Non Contact Surface Roughness Gauge

1. Handheld Non Contact Surface Roughness Gauge adopted pull aluminum mold design, durable, anti-electromagnetic interference ability significantly, in line with the design of the new trend.

2. Using high-speed DSP processor for data processing and calculation, measurement and computation speed is greatly improved.

3. Liquid crystal display wide temperature using OLED color display, popular high brightness, no visual angle,, is suitable for various occasions.

4. The lithium ion rechargeable battery, can work for a long time, no memory effect, can while charging, charging time is short, long battery life.

5.Charging and communication using the common USB interface. Using a dedicated charger or computer USB port for charging, convenient and quick.

6. Dot matrix liquid crystal display, interface prompt information rich.

7. Real-time monitoring of lithium battery power and display, and to remind users to charge with charging progress indication.

8. Automatic shutdown function and low power design of software and hardware of the instrument with long working hours, suitable for field use.

Parameter of Handheld Non Contact Surface Roughness Gauge

Testing parameters(µm )

Ra, Rz

Stroke length(mm)

6

Sample length(mm)

0.25 ,0.80 ,2.50

Evaluation length(mm)

1.25 ,4.0 ,5.0

Measuring range(µm )

Ra:  0.05 ~ 10.0  Rz:  0.1 ~ 50

Error

±10%

Variability

<12%

Contacting pin round diameter

10 µm±1 µm

Battery

3.7V Li

Size

106 mm×70 mm×24 mm

Weight

200g

Stylus static force

≤ 0.016N

Force measuring rate of change

≤ 800N/m

Temperature

-20℃~60℃

Relative humidity

<  90%

Pictures of Handheld Non Contact Surface Roughness Gauge
