ZBL-T720 Digital Thickness Gauge Meter

ZBL-T720 Digital Thickness Gauge Meter is professionally designed with a high sensitivity receiving system and mini receiver probe. The measuring range is 50mm ~ 560mm, and the testing accuracy is muc

Product Recommendation

  • Product Introduction
  • Product Parameter
  • Product Picture
  • Product Comment

Introduction of ZBL-T720 Digital Thickness Gauge Meter

1. ZBL-T720 Digital Thickness Gauge Meter is professionally designed with a high sensitivity receiving system and mini receiver probe. The measuring range is 50mm ~ 560mm, and the testing accuracy is much better than other similar products. It is an outstanding and world leading product.

2.Double-sided measuring the thickness of tested board. Neither preliminary work nor couplant is needed.

3.Testing results are accurate, testing method is simple and convenient. Thickness results displayed immediately.

4. ZBL-T720 Digital Thickness Gauge Meter can Real-time display of test data, smart estimation of the thickness value, and automatic saving of the test values. The test results are accurate and reliable.

5.Original data is saved automatically; statistical analysis results can be checked onsite.

6. USB port allows easy transfer of data to a PC.

7. Extension bar and multi-directional probe make the taking of measurements convenient, fast, and reliable.

8.A USB port is used to transfer the test results to a computer, for data storage and further analysis

9.Powerful and professional analysis software provides comprehensive later stage data processing and automatically generates test reports.

10.Rechargeable lithium battery enables long operating times, is convenient to use and both economically and environmentally friendly.

Parameter of ZBL-T720 Digital Thickness Gauge Meter

Item

Specification

Item

Specification

Thickness measuring range

50mm~560mm

storage

200 projects or 14,500 tested points

Accuracy

±1mm

50mm~350mm

monitor

320×240、5.1 LCD inch screen



±2mm

351mm~560mm

Power

Built-in lithium battery

Main instrument

size

190mm×135mm×52mm

Operating time

Main instrument

12hrs



weight

0.74kg(battery included)



Emitting transducer

30hrs

Pictures of ZBL-T720 Digital Thickness Gauge Meter
